EPICON 7335
Quick Nesting · Drilling · Grooving · Milling
The HOLZ-HER EPICON Series delivers advanced 5-axis CNC machining with exceptional precision, speed, and flexibility. Featuring a robust gantry design, direct servo-drives, and a powerful 13 kW spindle, the EPICON 7335 is ideal for furniture production, stair construction, model making, and solid timber processing.
- Crafted with precision
Product Features
Design
Advanced 5-axis CNC technology with a fully interpolating 13 kW spindle enables complex machining operations with exceptional accuracy, flexibility, and productivity.
- Crafted with precision
Product Features
Design
Optimized gantry construction, direct servo-drives, and precision linear guides deliver high acceleration, cutting speeds, and consistent machining quality across large workpieces.
- Crafted with precision
Product Features
Design
Generous machining capacities of up to 7,280 mm in the X direction, 2,100 mm in the Y direction, and a machining height of up to 300 mm provide maximum versatility for demanding applications.
- Innovation. Automation. Satisfaction.
Design Features
With all Farnese machines, we pride ourselves on making features simple to use. Our commitment to intuitive design ensures ease of operation and minimal training requirements.
Whether for furniture production, staircase construction, model making, or solid timber processing, the EPICON 7335 delivers industry-leading precision, flexibility, and performance.
13 kW 5-axis spindle, 131 m/min vector speeds, and servo drives deliver fast, accurate machining.
Rigid gantry, covered linear guides, and a 10-year HOLZ-HER guarantee ensure lasting reliability.
CAMPUS control provides intuitive programming, simple operation, and seamless workflow integration.
User-friendly controls and intuitive software enable fast setup and quick operator confidence.
Ideal for furniture, stairs, solid timber, model making, and precision 5-axis CNC machining.
SafeDetect, advanced tables, automation, and custom options adapt to your production needs.
Technical Specifications
Scroll horizontally to view all specifications.
| Technical Specifications | EPICON 7335 | Options |
|---|---|---|
| Machining dimensions in X-direction | 3680 / 4580 / 5480 / 6380 / 7280 mm | |
| Machining dimensions in Y-direction | 2100 mm | |
| Vector speed | 131 m/min | |
| Cutter unit |
13 kW, liquid-cooled 1000 – 24,000 rpm |
18 kW, liquid-cooled 1000 – 24,000 rpm ChipControl Bluetooth spindle sensor |
| Drilling head S | 14 spindles (10 V | 4 H), including sawing unit in X-direction | Second double drilling spindle in X-direction |
| Drilling head L | 21 spindles (15 V | 6 H), including sawing unit in X-direction | |
| Drilling head XL | 31 spindles (35 V | 6 H), including sawing unit in X-direction | |
| Additional drilling equipment | Second double drilling spindle in Y-direction Third double drilling spindle in X-direction Additional sawing unit in Y-direction | |
| Workpiece support | 6 pneumatically clamped consoles, each with 1 stop bolt at the front and rear and 2 suction cups measuring 115 x 140 x 125 mm | VISE LED table Display for consoles and suction cups, including the type of suction cup and rotation angle in 15° increments using coloured LEDs Synchro Drive-Table Fully automatic, software-controlled machine table for synchronous positioning of consoles and suction cup assemblies |
| Safety equipment | Safety mat | Safe Detect variable safety system using sensors |
| Workpiece clamping | 100 m³/h vacuum pump, dry-running version | Additional dry-running vacuum pumps |
| Tool changer | Travelling magazine plate for 18 tools in X-direction | Travelling magazine plate for 24 tools in X-direction Single magazine for large-diameter saw blades up to 350 mm Linear pick-up tool changer for 14 tools, permanently installed on the right side of the machine |
| Software | CAMPUS software machine licence, including aCADemy CAD/CAM module CAMPUS 3D material removal simulation | CAMPUS software office licence 5-axis simultaneous cutting |
| Machine monitoring | viaCockpit |
Technical data is provided for reference and may be subject to changes in design and equipment.
